1080P 2MP Surveillance cameras Hi3531A 16CH/8CH XMeye WIFI DVR 5 in 1 Coaxial Hybrid Onvif NVR TVI AHD CCTV DVR Free Shipping


Compare

$90.00

Buy product

ahd-camera-for-dvr_01ahd-camera-for-dvr_02ahd-camera-for-dvr_03ahd-camera-for-dvr_04ahd-camera-for-dvr_05ahd-camera-for-dvr_06ahd-camera-for-dvr_07ahd-camera-for-dvr_08

1080P Surveillance cameras Hi3521A 16CH 8CH XMeye WIFI DVR 5 in 1 Coaxial Hybrid Onvif NVR TVI AHD CCTV DVR Free ShippingHisiclion Sensor Dahua Exterior 16 Channel Two SATA Interface Four in One Coaxial 1080P NVR  TVI  AHD DVR picture 05AHD DVR Channel type

16CH



  • Pure Analog;16*1080P;16*1080N; 8*1080P;
  • Mixed;8*1080P(Analog)+8*1080P(Network)
  • Pure Network;8*1080P+8*960P;8*3M ; ;4*5M



8CH



  • analog; 8*1080P8*1080N
  • Network only;8*1080+8*960P,16*960P,4*3M,4*5M
  • hybrid; 4*1080P(analog)+4*1080P(network)



what is1080P AHD-H DVR


Q:
What is 1080P  AHD-H DVR?





A:
1080P Coaxial DVR is highest format HD DVR; the quality is best for all HD DVR; it is Support 2 million pixels(1080P/AHD-H),1.3 million pixels(960P/AHD-M), 1 million(720P/AHD-M) pixels AHD Camera ,960H,D1  and TVI,CVI Camera.





5-in-1 ahd hybrid dvr


Q:    What is 5 in 1 function?





A:    5 in 1 means that support AHD(AHD Camera),DVR(analog),NVR(IP Camera) ,TVI(TVI Camera)  and CVI Camera







1080P Surveillance Camera XMeye Hi3521A 16 Channel 16CH 1080N 5 in 1 Coaxial Hybrid Wifi TVi CVI IP NVR AHD DVR FreeShipping 02



Q:   What is XVI  function?



A:   XVI also known as AXVI (Full name is Advanced XM Video Interface), it is a coaxial transmission video format newest developed by XM. Products with XVI are superior to competitors not only because of its compatibility with AHD,TVI protocols, but also its unique feature.







XMeye 1080P 2mp Hybrid Coaxial 5 in 1 CCTV Camera 1080N  8CH4CH Surveillance Video Recorder TVI CVI NVR AHD DVR Free Shipping 01what is ahd dvr

1080n 16ch ahd dvr pictureHybrid ahd dvr Product Show

Xmeye App 16CH and 8CH 5 in 1 Surveillance Camera 1080N,1080P,960P,720P Hybrid IP 5 in 1Onvif NVR TVI AHD CCTV DVR Free Shipping 02


16CH:


Xmeye App 16CH and 8CH 5 in 1 Surveillance Camera 1080N,1080P,960P,720P Hybrid IP 5 in 1Onvif NVR TVI AHD CCTV DVR Free Shipping 03


Blue-Ray 1080P,1080N,960P,720P,960H 16CH and 8CH 5 in 1 WIFI Coaxial Hybrid TVI NVR AHD CCTV DVR Surveillance Video Free Shipping 04Blue-Ray 1080P,1080N,960P,720P,960H 16CH and 8CH 5 in 1 WIFI Coaxial Hybrid TVI NVR AHD CCTV DVR Surveillance Video Free Shipping 06





8CH:

Xmeye App 16CH and 8CH 5 in 1 Surveillance Camera 1080N,1080P,960P,720P Hybrid IP 5 in 1Onvif NVR TVI AHD CCTV DVR Free Shipping 08


Hisiclion Sensor Silver White Metal Case 1080P,1080N, 960P,720P 8CH and 4CH Coaxial Hybrid 5 in 1 TVI CVI NVR AHD DVR  Free Shipping 03Hisiclion Sensor Silver White Metal Case 1080P,1080N, 960P,720P 8CH and 4CH Coaxial Hybrid 5 in 1 TVI CVI NVR AHD DVR  Free Shipping 05

16CH 1080P DVR Screenshots:

Hi3531A Chip 16CH Two SATA Coaxial Hybrid ahd dvr picture 01

Hi3531A Chip 16CH Two SATA Coaxial Hybrid ahd dvr picture 03

IMG_2195

Hi3531A Chip 16CH Two SATA Coaxial Hybrid ahd dvr picture 02

IMG_2199

Hi3531A Chip 16CH Two SATA Coaxial Hybrid ahd dvr picture 04

Hi3531A Chip 16CH Two SATA Coaxial Hybrid ahd dvr picture 05



8CH 1080P DVR Screenshots:

IMG_20160929_121423





1080P AHD dvr main menu



HTB12VUKNFXXXXb2aXXXq6xXFXXXt



IMG_20160929_093918



IMG_20160929_093927





IMG_20160929_101739



IMG_20160929_101803





8ch ahd dvr Channel type



basic parameters picture

16CH


























  Model  6016T-MH(S)
System Main processor Hi3531A
Video Video codec H.264
Encode 16*1080N/16*1080P
Decode 16*1080N/16*1080P
Multi-mode

input


Pure Analog;16*1080P;16*1080N; 8*1080P;


Mixed;8*1080P(Analog)+8*1080P(Network)


Pure Network;8*1080P+8*960P;8*3M ; ;4*5M
Audio Audio

compression
G.711A
Intercom  support
Recording

and

Playback
Record mode  Manual>alarm>motion detection>timing
Playback

Channels
16(pure local input mode)
Storage

and

backup
Space

occupation
960H:12~20G/ day*channel

720P;~20G/ day*channel

1080P 20~30G/ day*channel

audio:691.2M/ day*channel
Backup mode Network backup,USB HDD, USB writer,SATA

writer
Interface Video input  16 BNC
Video output 1ch VGA,1ch HDMI
Audio input 2ch RCA
Audio output 1ch RCA
Alarm input 4
Alarm output 1
Network

interface
RJ45 10M/100M /1000M Adaptive Ethernet

port
PTZ control  RS485;support multiple PTZ protocols
USB  2 USB ports
Hard disk 1 SATA(Each maximum support 6T)
Wireless 3G,WIFI(expand via USB)
Other  Power 12V/3A
dimension(MotherBoard) 350mm(length)* 296mm(width)* 44mm(height)



Notice:

          12V 2A Power adpater 16CH AHD Hybrid DVR will not work with 2TB,3TB or 4TB hard disk ,so must use 12V 3A power adpater!!!(many seller use 12V 2A for cutting cost,so be careful)



8CH

































  Model  6008T-MH(S)
System Main processor Hi3521A
Interface Preview 1/4/8/9
Video  Codec H.264
Monitor quality VGA,HDMI:HD
Encode abilit 8*1080N/8* AHD-H@15fps
Decode ability 8*1080N/4* AHD-H@15fps
Onvif support
Multi-mode input


analog; 8*1080P,8*1080N


Network only;8*1080P+8*960P,16*960P,4*3M,4*5M


hybrid; 4*1080P(analog)+4*1080P(network) ;


Motion Detection Each screen can be set to 192 (16 * 12) detection areas; multi-level sensitivity can be set (Limited local channel)
Audio Audio compression G.711A
Intercom support
Record & playback Record mode  manual>alarm>motion detection>timing
Local Playback 4ch(local input mode)
Search mode Search by time, calendar, event, channel
Storage & backup Video storage  HDD, network
Backup mode Network, USBhard disk, USB burner, SATA burner
External Interface  Video input  8ch BNC
Video output 1ch VGA, 1ch HDMI
Loop Vout N/A
Audio I/O 4ch RCA ( Can be extended to 8ch)/1ch RCA
Alarm I/O  0(Can be extended to 4ch)/0(Can be extended to 1ch)
Network interface  RJ45 10M/100M self-adaption
PTZ control 1*RS485, Support kinds of PTZ protocols
USB 2* USB 2.0 ports
HDD 1*SATA ports (Max 6TB/per)
Wireless 3G, WIFI (extend via USB)
General Power supply  12V/2A
Power Consumption <15W (without HDD)
Working environment  Temperature:0degree-+55degree,Humidity:10%-90%,Atm:86kpa-106kpa
Dimension(motherboard) 218mm*93mm
Weight (motherboard) 220g



Hybrid AHD DVR shipping time and ways



  • 1.Russian Federation: 7-22 days By RETS-Express

  • 2.Brazil: 15-30 days E-Packet

  • 3.East Asia (Japan and Korea): 7-15 days EMS or E-Packet

  • 4.Southeast Asia: 7-15 days E-packet or Singapore Post

  • 5.Central Asia and South Asia: 7-20days China post

  • 6.West Asia (Israel): E-Packet; Netherlands Post; Swiss Post, about 15-30 days

  • 7.United States and Canada: 7-15 days E-Packet

  • 8.Europe: E-Packet; Netherlands Post; Swiss Post, about 7-15 days

  • 9.Oceania (Australia and New Zealand): 7-15 days E-Packet

  • 10.DHL (America and Europe):3-10days;SPSR(Russian Federation):7-18days





​Friendly Reminder:

  • we only spent two days (48 hours)  for sent parcel , have tracking number and tracking number information,Thanks!

  • if you choose DHL for sent goods, please make sure that your address is not in remote areas for DHL,because it will produce huge transportation costs for remote areas, this also need pay by buyer,Thanks!

  • Due to different custom policy of many country, If want avoid high custom tax, we can declare a low price for goods with your request,we often delcare $18 for this hybrid dvr,Thanks!



Notice:

        If you want to use WIFI function , please click the following button to buy USB WIFI Antenna Module,Thanks!

 HTB1EATpKFXXXXccXXXXq6xXFXXX14CH8CH 01

HTB1qGAwRXXXXXcFXFXXq6xXFXXXe

HTB1HC6laAfb_uJkSne1q6zE4XXa7

Power Adapter Standard



 HD power standard picture 01

 Hisiclion Chip Dahua Exterior Metal Case 16 Channel 1080P,1080N,960P,720P,960H Four in One TVi NVR AHD DVR  Accessories picture 01

 XM ahd dvr and cctv camera remote control by computerand phone

 FACTORY PIACTURECERTIFICQTION PICTURE

ahd camera and dvr gifts

11

NOTICE:



Q:  it always cause problems in trade between countries, for example , bad weather for delay, custom problem , post worker broken it, and so on


A:if you have any problem, please frist contact us, not easy input dispute or give me a bad feedback,  we will try our best to help you reslove problem ,We welcome those friendly customers,Thanks!





Category:
Technology

Analog,HDCVI,HDTVI,Network,AHD

Main processor

Hi3531A/Hi3521A

IP Mode

Static IP address

Video Standard

PAL

Video Output

1CH HDMI 1920X1080 60Hz

HDD Capacity

4TB

Brand Name

TVPSii

Compression Format

H.264

Hard disk Port

1 SATA

Supported Mobile Systems

iPhone OS,Android

APP

XMeye

Language

27 Multi language(English,Spain)

Warranty

one Year

Remote Control

yes

P2P Cloud

http://www.xmeye.net

Applicable camera

AHD,TVI,CVI,IP,Analog camera

e-Cloud(P2P)

Yes

Audio Output

1CH RCA

Hard Drive Size

3.5''

DVR Power Supply

DC12V

Wireless Security

WEP

Communication Interface

RS485

Hard drive Interface Type

SATA

Model Number

6008T-MH(S)/6016T-MH(S)

Video Input Interface

BNC (1.0 Vp-p, 75Ω)

Alarm Action

Local Alarm,FTP Photo,Email Photo

Audio Input

4 Channel,2 RCA

Network Protocol

TCP,DHCP,SMTP,HTTP,DDNS,UPNP,PPPOE,FTP,TCP

Audio Compression Format

G711A

Network Interface

RJ45 10/100M

Two-way Audio

No

Backup Type

Hard Drive

Video Resolution

1080P

Video Adjustment

Brightness Adjustable

Supported Operating Systems

Microsoft Windows XP,Microsoft Windows Vista,Microsoft Windows 7,Microsoft Windows 2000,Mac os

Format

PAL/NSTC
