1.5U Casing 16CH 2.0MP/9CH 5MP NVR With 16Port POE Power For 3MP/1080P POE IP Camera Video Recorder CMS Software Onvif P2P View


Compare

$368.66 $455.14

Buy product








1.5U Casing 16CH 2.0MP/9CH 5MP NVR With 16Port POE Power For 3MP/1080P POE IP Camera Video Recorder CMS Software Onvif P2P View

item pictures

IMG_2190N6000-16EFP-BIMG_2200IMG_0628IMG_0629IMG_5855

IMG_5859IMG_5913IMG_5915IMG_9075IMG_9080

2

IMG_9082IMG_9083


PC001

GOOLINK

item description



• P2P cloud service, including cloud connecting, cloud monitoring, cloud transmitting to access IPC and NVR at any time and any place

• Support Onvif protocol, support High profile S, High profile G, compatible with different IP camera that based on Onvif, RTSP standard

• Support megapixel HD network video preview, storage and playback;

• Support search, playback and backup by event;

• Support all channel image display on one screen at same time, support 4 channels’ image display by mainstream,and 4 channels playback;

• Support monitor PTZ on preview mode

• Offer CMS for free

• support 4 SATA(4*4TB=16TB)+1 E-SATA HDD ports



Note:This 16ch poe nvr max Support 16pcs poe ip camera(with the POE Port,48V power supply)



Main Functions:

1. Preview channel can be switched to other channel randomly without changing the MAC which is convenient for the project construction;

2. The dendritic menu can be moved. Man-machine communication is more direct and the settings of parameters are more easy and convenient;

3. The mouse roller can realize 15x digital zooming which the enlarged image can be dragged and moved randomly under preview and playback modes;

4. Immediate snapshot and immediate view; the picture will be stored in an independent area in the HDD;

5. The recording playback is shown by time bar and different color represents different recording type.  It is very fast and easy to find check the recording;

6. Recording backup can be accurate to second. Any time period of backup is available;

7. The recording files in the USB disk can play directly in the playback interface while the snapshot pictures can be viewed directly;

8. Standard resolution which can be adjusted according to the display device in order to get the best image quality;

9. Adopt HDD sequence writing method and the data is written from 0 track which increase 2.5X lifetime of the HDD






































Model Number N6000-16EFP
Operating System Embedded LINUX operating system
Image Code Control Image code quality adjustable, variable bitstream and constant bitstream optional
Dual Stream Each channel can set main stream and sub stream
Video Standard 5MP(2592×1944)30fps/ 3MP(2048×1536)30fps/1080P(1920×1080)30fps
Monitoring Image Quality 5MP(2592×1944)/3MP(2048×1536)/1080P(1920×1080)/960P(1280×960)
Image Motion Detection Each screen can set mutiple detection areas and set 6-level sensitivity(IPC  Support)
Recording Playback Quality 9ch 960P/ 1080P playback, 4ch/3MP/5MP playback
Region Cover Every channel can set 4 cover regions(IPC Support)
Recording Mode

Support manual , auto, dynamic detection,

alarm trigger record mode(Partly  needs IPC Support)

Backup Way Support U disk, USB mobile HDD, USB DVD-RW, network storage and backup
Operation Way Mouse, Keyboard
Local Login User name and password
Recording Storage Local HDD, network
Video Input 1,16×1920*1080)+sub960*576+4Ref.+9Play  16ch 2.0MP IPCamera
2,9×(2048*1536)+sub960*576+4Ref.+4Play  9ch 3.0MP IP Camera
3,9×(2592*1944)+sub960*576+4Ref.+4Play  9ch 5.0MP IP Camera
Audio Input 9ch/16ch network audio input, 1ch RCA output
Video Output 1ch VGA+1ch HDMI
Network Port 1 RJ45,10M/100M/1000M self-adaptive LAN port
Alarm Input 4ch/9ch
Alarm Output 1ch
USB Port 1 USB 3.0 port, 2 USB 2.0 ports
HDD Port 4 SATA HDD Port+1 E-SATA
MAX  Capacity Each port supports MAX 4TB HDD
POE Port 16pcs POE Port,Support 16ch poe ip camera(48v power supply)
Mobile Surveillance Support( Ios, Android) smart phone
Power Supply ATX110-220V 350W 50-60Hz
Power Consumption ≤208without HDD
Working Temperature -10
Working Humidity 10-90
Weight(without HDD) N.W.:5.7Kg;With packing:6.9Kg
Dimension Equipment:440mm×360mm×70mm, Packing: 460mm×135mm×560mm
Outside Carton  4 pcs/carton. 480mm×560mm×575mm; Weight:30 Kg
 Installation Way Desktop Installation





Packing List:

1 x 16CH POE 1080P/3MP/5MP NVR

1 x DC 12V Power Adapter

1 x Screws Set

1 x USB Mouse

1 x HDMI Cable

1 x CD with Mobile Software and NetViewer

1 x User Manual





NOTICE:


Our DVR NVR Or Surveillance System Does NOT Included The HDD,


If You Need It, Please Kindly Click The Photo As Below, Add It In Your Order List, Thanks !










1234567





Category:
Hard Drive Size

3.5''

POE

16 Port

Alarm input:

4ch/9ch Alarm input

Audio

16ch/9ch audio in, 1ch RCA audio out(must be ipc supoort)

Playback resolution

9*1080P/4*3MP/5MP

Digital input

16ch 1080P(1920*1080) /9ch 3MP(2048*1536)/ 5MP(2592*1944)

Screen display

1/4/9/16

Power Source

EU/AU/US/UK

Two-way Audio

No

IP Mode

Dynamic IP address

Network Interface

RJ45 10/100M

Brand Name

Unitoptek

Compression Format

H.264

Audio Input

1 RCA

Backup Type

Hard Drive

Alarm Action

Local Alarm

Video Output

HDMI, VGA

Model Number

N6000-16EFP

Video Standard

NTSC,PAL

Video Input Interface

HDMI

e-Cloud(P2P)

Yes

Supported Mobile Systems

iPhone OS,Android

Audio Output

1CH RCA

Hard drive Interface Type

SATA

Technology

Network

Communication Interface

RS485

Video Resolution

1080P

Standard machine cabinet

1.5U
